G25-660 DBB, .70A/R Cover, Billet Comp. Wheel, .72A/R Dual V-Band, 2.5" Inlet, 3" Outlet
Dual Ceramic ball bearing system provides optimal turbo response &
better durability by reducing the shaft-motion
9 Blade G-Aero Billet Compressor Wheel with Extended Tapered Tip Technology
9 Blade G-Aero Inconel 713c Turbine Wheel
Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port
Internally Wastegated, Billet Actuator(12-14 psi)
Hp Rating: 350-660
Engine displacement: 1.4-3.0L
Description
Compressor Wheel: 54*67mm
Turbine Wheel: 54*49mm
Compressor Inlet: 3″ Hose
Compressor Outlet: 2″ Hose
Turbine Inlet: 2.5″ V-Band
Turbine Outlet: 3″ V-Band
Water Ports: -6AN
Oil Feed: -4AN to the Oil Restrictor
Oil Drain: Std T3 Oil Drain Flange
